IPDirector Version 5.9 – User Manual – Part 4: Ingest
EVS Broadcast Equipment – January 2011
Issue 5.9.B
11
Selected Menu Item
Recorders / streams displayed
hi-res
recorders
hi-res
streams
lo-res
recorders
lo-res
streams
No selection X
Recorder LoRes X X
Streams HiRes X X
Streams LoRes X X X
Menu Item Description
Off-line
Channels
Displays or hides off-line recorder channels, i.e. recorder
channels available based on the EVS video server setup but
not used.
Selected only Displays the recorder channels for which the checkbox at the
left of the recorder name has been selected.
My Schedules
only Displays only the scheduled blocks created by this user.
Show
categories Displays only the blocks corresponding to the selected
categories. A sub-menu allows the user to select a single
option between the following: All categories, No category, or
the different categories defined. For more information on where
to define ingest block categories, see the section ‘Fields in the
New Schedule window’ on page 29.
2.3.3 C
URRENT
D
ISPLAY
F
ILTER
A text line gives information on the recorders and streams to be displayed in the
Ingest Scheduler main window according to the selection made in the Display
Options menu.
This information is the concatenation of three pieces of information about
1. selection of off-line and/or on-line recorders
2. selection of hi-res recorders, hi-res streams, lo-res recorders and/or lo-res
streams
3. selection of My Schedules option and/or Selected Category option.
The table below indicates the different messages displayed depending on the
selected Display options.
