Inputs

Description

Number of logical record channels in the given configuration.

The partition of the disk storage between these channels, and
the advanced audio settings are automatically adapted to the
number of record channels.

Values

The number of supported channels depends on the chassis,
and the mode:

On XS 6U: 0-6 (all config.)

On XS 5U: 0-4 (all config.)

See section "General Information on Supported
Configurations" on page 56
for more information on number of
record channels and on supported configurations.

Outputs

Description

Number of logical play channels in the given configuration.

Values

On XS 6U: 0-6 (all config.)

On XS 5U: 0-4 (all config.)

See section "General Information on Supported
Configurations" on page 56
for more information on number of
record channels and on supported configurations.
