Keyword info
Description Shows / hides the defined keywords and ranking on the OSD
of the output monitors when the clip is loaded on its Short IN
point.
As soon as the operator starts jogging into the clip or initiates a
playback, this information is removed from the OSD so that
the video content is clearly visible.
Values Yes / No (default)
OSD on outputs
Description Enables / disables the OSD on the play channels.
Values Yes (default) / No
OSD on inputs
Description Enables / disables the OSD on the record channels.
Values Yes (default) / No
Background
Description Applies a dark gray background to the OSD display.
Values Yes / No (default)
3.9.3. Audio Meters OSD Settings
Introduction
The Audio Meters OSD settings allow users to specify whether and how the audio meters
are to be displayed on the OSD.
These fields are available in the following interfaces:
• in the Multicam Configuration window, Operation tab, in the basic display mode on
page 1 on the server- and web-based interfaces.
• in the Operational menu of the Remote Control Panel (1.2).
The following screenshot presents page 1 of the Operation tab in the server-based
application, where the Audio Meters OSD settings are available, and highlights this
settings area:
