Audio Connectors

Description

Type of connectors available in the hardware configuration.

The audio formats available on the EVS server, and in the
Advanced audio settings pages, depend on the audio
hardware configuration.

Note that the values defined on this field are not validated
against the real hardware configuration.

Values

The following table shows the available audio hardware
configurations, and the available audio formats based on this
hardware configuration:

Hardware configuration

Available formats

None

E (Embedded)

EY (Dolby E Embedded)

4 DB 15 A + 16 BNC D

E - EY - A - D - DY

4 DB 15 A + 4 DB 15 D

E - EY - A - D - DY

Number of Tracks

Warning

A change to this parameter requires an application reboot (ALT+Q from the
operational windows) to be taken into account.

Description

Number of mono audio tracks associated to each video
channel.

Values

4 Monos (default), 8 Monos or 16 Monos

Audio Full Scale

Description

Maximum audio level for the analog outputs on the server (in
dB).

It allows indirectly defining the head room, as the audio full
scale is 4 dB higher than the head room. As the default value
for the audio full scale is 22 dB, the default value for the head
room is 18.

Values

Range of values: [10…30] dB

Default value

22 dB
