3.9.2.

OSD Settings

Introduction

The OSD settings allow users to specify which and how the information will be displayed
on the OSD.

These fields are available in the following interfaces:

in the Multicam Configuration window, Operation tab, in the basic display mode on
page 1 on the server- and web-based interfaces.

in the Operational menu of the Remote Control Panel (1.1).

The following screenshot presents page 1 of the Network tab in the server-based
application, where the OSD settings are available, and highlights the OSD settings area:

Cue number on OSD

Description

Enables / disables the display of the cue point number on the
OSD of the output monitors when a cue point is recalled inside
a record train.

Values

Yes (default) / No
