3.2.

Supported Configurations

3.2.1.

General Information on Supported
Configurations

Overview on Supported Configuration Types

An XS server, equipped with V3X or COHX boards, supports the following configurations
types:

standard SD/HD configurations

3D/1080p configurations

Note

The feature 'Mix on one channel' for play channels is available on the
SD/HD configurations with V3X boards.

The feature 'Two recorders per codec module' is not available.

Number of Record and Play Channels

The number of record and play channels for a given configuration is defined in the
Channels tab, in the Base settings. See section "Base Settings" on page 86.

This section presents the number of channels available on an XS server.

The number of record and play channels that can be operated vary based on the chassis
type. The following table shows the minimum and maximum number of channels that can
be operated:

6U

(V3X )

5U

(V3X or COHX)

Max. # channels

6

4

Min. # REC

0

0

Max. # REC

6

4

Min. # PLAY

0

0

Max. # PLAY

6

4

XS Server - Version 11.01 - Configuration Manual

3. Multicam Configuration

56
