Ancillary Mode
Availability This setting is displayed in SD configurations.
Description Encoding method used for digital audio.
Values 20 Bits / 24 Bits (default)
Sample Rate Conv. (Conversion)
Description Specifies whether the input sample rate is converted. This
parameter is only available with the digital AES/EBU audio
format.
If this parameter is set to 'No', the user has to ensure that the
signals are properly synchronized.
Values Yes (default) / No
Audio Monitoring: Mon #1 - Mon #4
Description Specifies the source of the audio signal that will be sent to
each of the four audio monitoring connectors (numbered from
left to right on the backplane).
Value For each audio monitoring connector, the audio signal to be
monitored is specified by the video channel number and the
audio mono channel number.
Example: The value 'OUT1-01' for Mon #1 means that the
audio signal of the 1st audio mono channel of the PGM1 is sent
to the monitoring connector 1.
Default Values By default, the audio signal of the first play channel, and the
audio mono channels from 1 to 4 (OUT1-01 to OUT1-04) are
respectively assigned to the Mon #1 to Mon #4 connectors.
