GX server – Version 1.10 – User Manual

EVS Broadcast Equipment – September 2012

Issue

1.10.D

35

How to Disconnect an EVS Server

To disconnect an EVS server, select it in the tree structure, click the

symbol at the top,

and confirm the disconnection.

5.3 Selecting and Importing Source

Materials

Once the drives containing the source files are available in the tree structure, you can

easily select the requested sources files and import them.
Once imported, the source files are stored onto the archive disk, so that they will still

remain available for future use.

5.3.1 Source Material List

The source files or clips available in the location selected in the tree structure are

displayed in the Source Material list, on the right hand of the Import area.
This list allows you to select the files or clips that you will import using the

Direct Online

or the

Import button. For more information on importing files, refer to the section 5.3.3

'How to Import Files on the GX Server', on page 38.
When a source file has already been imported onto the GX server, the corresponding row

is dimmed in the Source Material list.

5.3.2 Fields in the Source Material List

When the Source Location is a Drive or Folder

The list of source files provides the following information. The field values are not

editable, unless otherwise is stated in the table.

Field Name

Description

Values

Name

Name of the audio file or the

graphic file sequence.

Duration

(frame)

Number of frames in the

video sequence.

The value will be '1' for audio files.
