To disconnect the network drive, select it in the tree structure, click the – symbol at the
top, and confirm the disconnection.
5.2.4 How to Connect and Disconnect an EVS
Server
How to Add an EVS Server from Another IP
Address Range
This procedure applies to GX servers whose IP Address is not in the same subnet range
as the IP Address of the EVS server.
To map an EVS server onto the GX server, proceed as follows:
1. Click the
+ symbol at the top of the tree structure.
A list opens.
Note
If you want to close the list without taking any action, click the + symbol
again.
2. Click the Add XT server item.
The Connect to XT window opens.
3. Type the PC LAN IP address of the EVS server to be mapped in the XT IP Address
(PC LAN) field.
4. The User and Password fields are correctly pre-filled to connect to an EVS server
version 11.0 or later. If the EVS server is a version 10.3 up to 10.5, and has other
login settings on its GigE ports, change the User and Password fields.
5. Click OK.
The selected EVS server is now available in the tree structure.
