EVS GX Version 1.10 User’s Manual - Manual (Page 40)

Issue
1.10.D
GX server – Version 1.10 – User Manual
EVS Broadcast Equipment – September 2012
32
The Raw Materials drive, which contains the imported files, is automatically displayed in
the tree structure.
5.2.3 How to Connect and Disconnect a Network
Drive
To map a network drive onto the GX server, proceed as follows:
1. Click the
+ symbol at the top of the tree structure.
A list opens.
Note
If you want to close the list without taking any action, click the
+ symbol
again.
2. Click the Connect a shared drive item.
The Map a shared drive window opens.
3. Type the full path to the folder to be mapped in the Network Path field, using the
following pattern: \\[ComputerName]\[FolderName].
4. Select a drive letter to be associated to this mapped drive.
5. Type an existing Windows user name to access the given machine in the
User field,
using one of the following patterns:
o [Domain]\[Username] or username@domain when the target computer and
username are part of a domain.
o [ComputerName]\[Username] or username@computername when username is
a local user account on the target computer.
6. Type the Windows password corresponding to this user name in the Password field.
7. Click OK.
The network drive is mapped to a drive letter, and is now available in the tree structure.
