GX server – Version 1.10 – User Manual
EVS Broadcast Equipment – September 2012
34
How to Discover EVS Servers in the Same IP
Address Range
This procedure applies to GX servers whose IP Address is in the same subnet range as
the IP Address of the EVS server.
To map an EVS server onto the GX server, proceed as follows:
1. Click the
+ symbol at the top of the tree structure.
A list opens.
Note
If you want to close the list without taking any action, click the + symbol
again.
2. Click the Discover XT server item.
The Discover XT window opens.
On the left side, a list of EVS servers found on the network is populated. On the right
side, the list containing the EVS servers to be mapped is empty.
3. Select one or several EVS servers in the list on the left, and click the > button
between the two areas. The items are added in the list on the right. If you want to
remove some items from the list on the right, click the < button.
4. Click OK.
The selected EVS servers are now available in the tree structure.
