GX server – Version 1.10 – User Manual
EVS Broadcast Equipment – September 2012
Issue
1.10.D
13
3. GX Server Setup
3.1 Chapter Overview
What about… ? Section Page
Cabling 3.2 Page 13
GX Server Installation and Ghost Restore 3.3.1 Page 15
Switching on versus Starting the Server 3.3.2 Page 15
3.2 Cabling
The GX server has to be cabled as shown on the schema below to allow:
• Users to import video sequences and audio files and to create the GX clips on the
server from the client PC.
• Operators to control the playout via the switcher.
Important
The GX server is connected to the protocol clients through the RS422 port.
Once the GX clips are ready for playout, the GX server however needs to be
manually started from the GX web interface for the communication between the
GX server and the protocol client to be established.
For more information on starting the GX server, refer to the sections 3.3.2
'Switching on versus Starting the Server', on page 15, and 4.2.5 'Starting the
GX Server', on page 23.
