Issue

1.10.D

GX server – Version 1.10 – User Manual

EVS Broadcast Equipment – September 2012

22

The table below describes the status information fields:

Option

Description

GX version

Software version number of the GX server.

Disk capacity

Remaining capacity on both Raw Materials and GX Clips

drives. It is expressed as a percentage of the total drive

capacity.

IP address

IP address of the network interface card (NIC) that allows the

GX server to communicate over the network.

Protocol

Protocol the GX server is currently set to work with.

Output format

Currently selected video standard.
When the GX server is started, only GX clips created in the

selected video standard will be visible to the protocol clients.

The value corresponds to the one selected in the

Video

Standard field in the Settings area.

Genlock status

Quality of the genlock signal.
The messages on the genlock quality can be the following:

Valid:

Good genlock

Bad (no signal):

No genlock signal detected

Bad (mismatch):

Genlock signal detected, but

not in the correct format

If the genlock quality is bad, the genlock information is

displayed in red. Otherwise, this is in green.

Running process

Activity status on the GX server:

The status is 'Importing' if raw materials are being imported

onto the Raw Materials drive.

The status is 'Setting online' if GX clips are being uploaded

onto the GX Clips drive.

The status is 'Idle' if there is no activity.

Status indication

GX server status:

The status is 'Not started' when the server is not running.

The status is 'Active' when the GX server has been started

and is awaiting commands.

Clip name

Name of the GX clip that has been loaded by the protocol

client.

GX message

Error, warning or general message reported by the GX server

and displayed on the OSD of the SDI Fill output.
