Issue

1.10.D

GX server – Version 1.10 – User Manual

EVS Broadcast Equipment – September 2012

16

3.4.2 Constraints

Connection to the Web Interface

Users can theoretically connect to the web interface of the GX server using the IP

addresses of both ports. If a GigE port is exclusively dedicated to the communication with

EVS video servers, the IP address of the second GigE port must be used for the remote

connection to the web interface.

Discovery of EVS Servers

The

XT Network Discovery Port parameter, in the Server Control window, specifies

which of both GigE ports is used to discover the EVS servers.
The GigE port of the GX server used for discovery must be on the same subnet as the

PC LAN IP addresses of the EVS servers.

Tranfer of Video Material

The IP addresses of the EVS servers' GigE port to be used for video transfer are

transferred as the GX server discovers the EVS servers.
The GigE port of the GX server used for video transfer must be on the same subnet as

the GigE IP addresses of the EVS servers.

3.4.3 Typical Configurations

Taking the constraints into account, many configurations are possible, but the following

ones are the most typical:

Single Port

In the first configuration, a single GigE port is used. The IP address of the GX server

GigE port is set as to be on the same subnet as the PC LAN IP address and GigE IP

address of the EVS servers.

Two Ports, Same Subnet for PC LAN and Gigabit Ports

In the second configuration, both GigE ports are used, and the PC LAN and GigE IP

address of the EVS servers are on the same subnet:

Port 1 of the GX server is used for the remote connection to the GX server.

Port 2 of the GX server is used for the connection to the network of EVS servers.
