Issue 2.13.D XFile Version 2.13 – User Manual
EVS Broadcast Equipment – July 2010
176
Appendix 1:
XF[2] Hardware
HARDWARE DESCRIPTION
The XFile software is installed in a workstation operating under Windows XP Pro.
The standard system is Intel Core2 Duo E6300 Processor, Intel Motherboard with
DRAM 1GB and an EVS PCX board.
Note
The PCX1 board is not compatible with XFile v2.00 and higher.
The hardware components of the XF[2] platform (formerly called XFile[2]) are
housed in a 3U rack cabinet equipped with 2 x ATA 133 750GB Mobile Cartridges.
The XF[2] platform is included in the XNet in which EVS video servers interact via
SDTI network.
This XF[2] platform is also equipped with two additional Gigabit Ethernet adapters
that support the jumbo frame mode for connections with the EVS video server
GigE ports and third parties.
