XFile Version 2.13 – User Manual
EVS Broadcast Equipment – July 2010
Issue 2.13.D
159
Note
The ShuttlePRO can be used to perform the commands corresponding to
the buttons of the IN-OUT tab in the Edit Clip window. For more
information on the ShuttlePRO configuration and use with XFile, refer to
section 5.2 ‘ShuttlePRO Use in Edit Clip Module’, on page 163.
5.1.3 G
RAB
O
PTIONS
From the IN-OUT tab of the Edit Clip module, the operator can select one image in
the main window (current position of the cursor) and press the Grab Field button
or the Grab Frame button to open the following dialog box:
File Area
Select the filename and the destination folder to save the JPG/BMP files.
Options Area
Stretch field to frame size
This option is only available with the Grab Field function. Should the Grab Frame
button has been pressed, the option is dimmed.
Enabling this option will automatically stretch the ‘field image’ to the original
‘frame size’.
Output format
The automatic selection of the output format depends on the previous option. If
the images are not modified by stretching, the JPG format is defined and if the
images are modified by stretching, the BMP format is selected. The user can force
the selection of one format.
