EVS Xfile Version 2.13 - July 2010 User Manual - Manual (Page 180)

XFile Version 2.13 – User Manual
EVS Broadcast Equipment – July 2010
Issue 2.13.D
171
5.3.3 F
IELDS IN THE
C
ONFIGURATION
W
INDOW
The following table describes the various fields in the Configuration window:
Field Description
Drop-down list box in which the user selects the
separator to be used in the TXT and CSV files to
separate the metadata values of a clip.
Left list box List of all selectable clip metadata.
Right list box Selection of clip metadata that will be exported
to an output file.
Button to remove from the selection the clip
metadata selected in the right table.
Button to add to the selection the clip metadata
selected in the left table.
Button to import a configuration file. The
configuration file that will automatically be
imported needs to be located in the folder
C:\Program Files\EVS Broadcast
Equipment\XFile and be called
XFile_ClipInfo_Exporter_Config_Fi
le.xml.
