8
ASRock Z77E-ITX Motherboard
English
1.2 Specifications
Platform - Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm
- Premium Gold Capacitor design (100% Japan-made
high-quality Conductive Polymer Capacitors)
CPU - Supports 3 rd and 2 nd Generation Intel ® Core TM i7 / i5 / i3 in
LGA1155 Package
- Digi Power Design
- 6 + 2 Power Phase Design
- Supports Intel ® Turbo Boost 2.0 Technology
- Supports Intel ® K-Series unlocked CPU
- Supports Hyper-Threading Technology (see CAUTION 1)
- Supports Intel ® Rapid Start Technology and Smart Connect
Technology with Intel ® Ivy Bridge CPU
Chipset - Intel ® Z77
Memory - Dual Channel DDR3 Memory Technology (see CAUTION 2)
- 2 x DDR3 DIMM slots
- Supports DDR3 2800+(OC)/2400(OC)/2133(OC)/1866(OC)/
1600/1333/1066 non-ECC, un-buffered memory
- Max. capacity of system memory: 16GB (see CAUTION 3)
- Supports Intel ® Extreme Memory Profi le (XMP)1.3/1.2
Expansion Slot - 1 x PCI Express 3.0 x16 slot (PCIE1: x16 mode)
(see CAUTION 4)
* PCIE 3.0 is only supported with Intel ® Ivy Bridge CPU. With
Intel ® Sandy Bridge CPU, it only supports PCIE 2.0.
- 1 x mini-PCI Express slot: For WiFi module
Graphics * Intel ® HD Graphics Built-in Visuals and the VGA outputs can
be supported only with processors which are GPU
integrated.
- Supports Intel ® HD Graphics Built-in Visuals: Intel ® Quick
Sync Video 2.0, Intel ® InTru TM 3D, Intel ® Clear Video HD
Technology, Intel ® Insider TM , Intel ® HD Graphics 2500/4000
- Pixel Shader 5.0, DirectX 11 with Intel ® Ivy Bridge CPU.
Pixel Shader 4.1, DirectX 10.1 with Intel ® Sandy Bridge
CPU.
- Max. shared memory 1760MB (see CAUTION 5)
- Multi VGA Output options: DVI, HDMI, DisplayPort and
D-Sub with the bundled DVI-to-D-Sub Converter
(see CAUTION 6)
- Supports HDMI 1.4a Technology with max. resolution up to
1920x1200 @ 60Hz
