10
ASRock Z77E-ITX Motherboard
English
SATA3 - 2 x SATA3 6.0 Gb/s connectors, support RAID (RAID 0,
RAID 1, RAID 5, RAID 10, Intel Rapid Storage and Intel
Smart Response Technology), NCQ, AHCI and Hot Plug
functions
USB3.0 - 2 x Rear USB 3.0 ports by Intel ® Z77 , support USB 1.0/2.0/3.0
up to 5Gb/s
- 2 x Rear USB 3.0 ports by ASMedia ASM1042 , support USB
1.0/2.0/3.0 up to 5Gb/s
- 1 x Front USB 3.0 header (supports 2 USB 3.0 ports) by
Intel ® Z77 , supports USB 1.0/2.0/3.0 up to 5Gb/s
Connector - 2 x SATA2 3.0 Gb/s connectors, support RAID (RAID 0,
RAID 1, RAID 5, RAID 10, Intel Rapid Storage and Intel
Smart Response Technology), NCQ, AHCI and Hot Plug
functions
- 1 x mSATA 3.0 Gb/s connector (Solid-State Drive
connector), supports RAID (RAID 0, RAID 1, RAID 5, RAID
10, Intel Rapid Storage and Intel Smart Response
Technology), NCQ, AHCI functions and Full-size mini-PCI
Express modules
- 2 x SATA3 6.0Gb/s connectors
- 1 x CIR header
- CPU/Chassis FAN connector
- 24 pin ATX power connector
- 8 pin 12V power connector
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
- 1 x USB 3.0 header (supports 2 USB 3.0 ports)
BIOS Feature - 64Mb AMI UEFI Legal BIOS with GUI support
- Supports “Plug and Play”
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- CPU Core, IGPU, DRAM, VCCSA Voltage Multi-adjustment
Support CD - Drivers, Utilities, AntiVirus Software (Trial Version),
CyberLink MediaEspresso 6.5 Trial, ASRock MAGIX
Multimedia Suite - OEM
Unique Feature - ASRock Extreme Tuning Utility (AXTU) (see CAUTION 9)
- ASRock Instant Boot
- ASRock Instant Flash (see CAUTION 10)
- ASRock APP Charger (see CAUTION 11)
- ASRock SmartView (see CAUTION 12)
