Navigating the Web Interface

27

System Time

Allows you to set the system time.

SNMP

Contains tabs that allow you to:

Set the SNMP Agent status.

Add community strings.

Remove community strings.

Device

Configures the device.

VLAN

Contains tabs that allow you to:

Create a VLAN.

Modify a VLAN.

Modify VLAN membership for a port.

Rename a VLAN.

Remove a VLAN.

Display VLAN membership for a port.

Display VLAN information.

Spanning Tree

Allows you to configure a Spanning Tree
Protocol.

IGMP Snooping

Allows you to enable or disable IGMP
snooping.

IGMP Query

Allows you to enable or disable IGMP query
mode.

Broadcast Storm

Allows you to enable and configure, or
disable rate limiting.

Port

Configures the ports.

Administration

Contains tabs that allow you to:

Display selected port information for the
entire Switch.

Display individual port information.

Modify the port settings.

Menu Item

Description

Link Aggregation

Contains tabs that allow you to:

Display link aggregation summary.

Create an aggregation group.

Modify the port memberships.

Remove an aggregation group.

Spanning Tree per
Port

Contains tabs that allow you to:

Display selected spanning tree informa-
tion for every port.

Display individual port spanning tree
information.

Modify the spanning tree settings for a
port.

Port Mirroring

Contains tabs that allow you to:

Display the current Port Traffic Monitor-
ing configuration.

Modify Port Traffic Monitoring settings.

Statistics

Display statistics for a selected port.

QoS

Configures QoS settings.

VoIP Traffic Setting

Contains tabs that allow you to:

Display Voice VLAN summary.

Configure Voice VLAN global settings.

Configure Voice VLAN port settings.

Display port information for Voice VLAN
and Trunk details.

Display OUI summary.

Add or remove OUI.

Security

Configures security settings.

Menu Item

Description
