York UL R134A - Manual (Page 87)

JOHNSON CONTROLS
FORM 201.23-EG1 (1007)
87
DIMENSIONS (mm) UNLESS OTHERWISE NOTED
POWER: SINGLE POINT WITH TERMINAL BLOCK
X
G
C
Y
VIEW D-D
B
846
2624 A
2865 2146
2387
D D
X
Z
10" (WATER INLET) 10" (WATER OUTLET)
A
A
231 1278 1270 2192 1770
33 (TYP)
16 MOUNTING
HOLES (TYP)
(3) RIGGING HOLES
EACH SIDE 76 X 51
ORIGIN
CONTROL
P
ANEL
1151
1524
358
