Page 26
JOHNSON CONTROLS
26
MODEL:YCIV0267S/P
AIR TEMPERATURE ON - CONDENSER (°C)
LCWT
25.0
30.0
35.0
40.0
45.0
46.0
(°C)
KWo
KWi
COP
KWo
KWi
COP
KWo
KWi
COP
KWo
KWi
COP
KWo
KWi
COP
KWo
KWi
COP
5.0
898.1
224.4
3.7
883.4
254.8
3.2
866.4
288.2
2.8
838.4
322.8
2.4
796.3
349.6
2.2
787.8
354.9
2.1
6.0
923.0
226.2
3.8
907.7
256.6
3.3
889.9
290.2
2.9
859.6
323.9
2.5
816.0
350.8
2.2
807.2
356.2
2.1
7.0
948.4
228.2
3.8
932.5
258.5
3.4
913.9
292.1
2.9
881.1
325.0
2.6
836.1
352.0
2.3
823.0
354.5
2.2
8.0
974.1
230.3
3.9
957.7
260.5
3.4
938.4
294.1
3.0
902.9
326.1
2.6
856.7
353.2
2.3
830.7
346.5
2.3
9.0
1000.4 232.5
4.0
983.4
262.6
3.5
963.2
296.3
3.0
924.9
327.3
2.7
877.6
354.4
2.3
838.5
338.4
2.3
10.0
1027.2 234.8
4.0
1009.5 264.8
3.5
988.6
298.4
3.1
947.5
328.5
2.7
894.1
352.2
2.4
846.3
330.4
2.4
11.0
1054.4 237.3
4.1
1036.0 267.2
3.6
1014.5 300.6
3.2
970.4
329.6
2.8
902.4
343.6
2.5
854.0
322.4
2.5
12.0
1081.9 240.0
4.2
1063.1 269.6
3.7
1040.8 302.9
3.2
993.6
330.9
2.8
910.6
335.1
2.6
861.4
314.7
2.6
13.0
1110.1 241.5
4.2
1090.4 272.1
3.7
1067.6 305.4
3.3
1017.3 332.1
2.9
918.5
326.8
2.7
868.2
307.6
2.7
MODEL:YCIV0287S/P
AIR TEMPERATURE ON - CONDENSER (°C)
LCWT
25.0
30.0
35.0
40.0
45.0
46.0
(°C)
KWo
KWi
COP
KWo
KWi
COP
KWo
KWi
COP
KWo
KWi
COP
KWo
KWi
COP
KWo
KWi
COP
5.0
954.4
236.0
3.7
936.9
271.1
3.2
916.5
309.6
2.8
877.6
343.2
2.4
793.2
350.5
2.1
746.0
331.2
2.1
6.0
981.3
237.5
3.8
963.2
272.4
3.3
942.0
311.0
2.8
899.5
343.6
2.5
800.8
343.6
2.2
754.0
324.7
2.2
7.0
1008.7 239.2
3.9
990.1
273.8
3.4
967.5
312.0
2.9
921.4
343.8
2.5
809.9
337.1
2.3
763.4
318.9
2.2
8.0
1036.6 241.0
3.9
1017.4 275.2
3.4
992.9
312.7
3.0
943.6
344.0
2.6
820.0
330.9
2.3
772.1
312.5
2.3
9.0
1065.0 243.1
4.0
1045.3 276.9
3.5
1018.8 313.5
3.0
966.3
344.1
2.6
829.3
324.3
2.4
780.4
306.1
2.4
10.0
1093.8 245.4
4.1
1073.7 278.7
3.6
1045.2 314.4
3.1
989.4
344.2
2.7
838.5
317.7
2.5
787.8
299.7
2.5
11.0
1123.1 248.0
4.2
1102.5 280.7
3.6
1071.9 315.4
3.2
1012.6 344.3
2.8
847.0
311.1
2.5
794.9
293.5
2.5
12.0
1152.9 250.7
4.2
1131.8 282.9
3.7
1099.0 316.5
3.3
1036.2 344.4
2.8
855.1
304.7
2.6
801.6
287.2
2.6
13.0
1183.2 253.6
4.3
1161.7 285.3
3.8
1126.6 317.6
3.3
1060.1 344.5
2.9
862.0
298.3
2.7
808.3
281.1
2.7
MODEL:YCIV0307S/P
AIR TEMPERATURE ON - CONDENSER (°C)
LCWT
25.0
30.0
35.0
40.0
45.0
46.0
(°C)
KWo
KWi
COP
KWo
KWi
COP
KWo
KWi
COP
KWo
KWi
COP
KWo
KWi
COP
KWo
KWi
COP
5.0
1060.5 260.2
3.7
1041.2 300.1
3.2
1019.7 344.5
2.8
975.0
381.9
2.4
870.2
379.2
2.2
817.1
356.4
2.2
6.0
1090.3 262.0
3.8
1070.2 301.3
3.3
1046.9 345.3
2.8
998.2
381.7
2.5
878.4
371.1
2.2
826.0
349.2
2.2
7.0
1120.9 263.9
3.9
1099.9 302.6
3.4
1074.3 345.7
2.9
1022.0 381.3
2.5
888.4
363.6
2.3
835.5
342.1
2.3
8.0
1152.1 266.2
4.0
1130.1 304.1
3.5
1102.2 346.2
3.0
1046.2 380.8
2.6
897.9
355.6
2.4
844.5
334.7
2.4
9.0
1183.8 268.8
4.1
1161.0 305.9
3.5
1130.7 346.9
3.1
1070.9 380.2
2.7
907.5
347.9
2.4
853.1
327.6
2.4
10.0
1216.2 271.7
4.1
1192.5 307.9
3.6
1159.8 347.7
3.1
1095.9 379.6
2.7
916.7
340.3
2.5
860.8
320.7
2.5
11.0
1249.2 274.8
4.2
1224.5 310.3
3.7
1189.3 348.6
3.2
1121.1 379.1
2.8
925.4
333.0
2.6
868.4
313.9
2.6
12.0
1282.9 278.4
4.3
1257.3 312.9
3.7
1219.4 349.7
3.3
1147.0 378.5
2.9
933.7
326.0
2.7
875.7
307.2
2.7
13.0
1317.1 282.4
4.3
1290.6 315.7
3.8
1249.9 351.1
3.3
1173.3 378.0
2.9
941.3
319.2
2.8
883.0
300.7
2.7
Standard Efficiency Ratings
– SI - 460V/60Hz
NOTES:
1. kWo
= Unit kW Cooling Capacity Output
2. kWi
= Compressor kW Input
3. COP
= Coefficient of Performance (includes condenser fan power)
4. LCWT = Leaving Chilled Water Temperature
5. Ratings based on 0.15 l/s cooler water per ton, and 0.018 (m
2
– °C)/kW
