JOHNSON CONTROLS
FORM 201.23-EG1 (1007)
79
POWER: SINGLE POINT WITH TERMINAL BLOCK
45 5/16"
26 3/8"
16 3/16"
A
A
X
G
C
Z
D
D
93 15/16"
CONTRO
L
PANE
L
337 3/16"
197 13/16"
15"
141 1/8"
238 5/8"
357"
33 3/16"
10" (WATER INLET)
10" (WATER OUTLET)
(4) RIGGING HOLES
EACH SIDE 3 X 2
70"
9 1/8"
49"
53"
93 5/8"
80 3/16"
83 1/8"
9 1/8"
ORIGIN
1 5/16" (TYP)
5/8" MOUNTING HOLES (TYP)
X
G
C
Y
7 5/8"
