JOHNSON CONTROLS
FORM 201.23-EG1 (1007)
43
NOTES:
1. kW = Compressor Input Power
2. EER = Chiller EER (includes power from compressors, fans, and control panels 0.8 KWi)
3. LCWT = Leaving Chilled Water Temperature
4. Ratings based on 2.4 GPM cooler water per ton
5. Rated IAW ARI Standard 550/590-98
MODEL: YCIV0357S/P S_IPLV = 13.7 P_IPLV = 15.4
AIR TEMPERATURE ON - CONDENSER (°F)
LCWT 75.0 80.0 85.0 90.0 95.0 100.0 105.0 110.0 115.0
(°F) TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER
40.0 336.3 282.3 13.1 333.4 303.7 12.1 330.1 326.9 11.2 326.6 351.0 10.4 322.9 376.4 9.6 318.6 404.9 8.9 309.3 423.4 8.2 298.3 437.9 7.7 287.4 451.6 7.2
42.0 346.9 284.7 13.4 343.8 306.1 12.4 340.4 329.1 11.5 336.7 353.3 10.6 332.8 378.7 9.8 328.3 407.4 9.1 317.7 424.3 8.4 306.3 438.9 7.9 295.0 452.8 7.4
44.0 357.7 287.5 13.7 354.5 308.7 12.7 350.9 331.5 11.7 347.1 355.8 10.9 342.9 381.2 10.1 338.1 409.8 9.3 326.3 425.1 8.7 314.6 439.7 8.1 302.8 453.8 7.6
45.0 363.2 288.9 13.8 359.9 310.1 12.8 356.3 332.9 11.9 352.3 357.1 11.0 348.1 382.6 10.2 342.7 410.2 9.4 330.7 425.4 8.8 318.7 440.1 8.2 304.8 449.8 7.7
46.0 368.8 290.5 13.9 365.4 311.4 13.0 361.7 334.2 12.0 357.6 358.4 11.1 353.3 383.9 10.3 347.2 410.5 9.5 335.1 425.8 8.9 322.9 440.5 8.3 306.7 445.3 7.8
48.0 380.1 293.7 14.2 376.6 314.5 13.2 372.7 337.0 12.3 368.5 361.1 11.4 363.9 386.6 10.6 356.5 411.3 9.8 344.0 426.5 9.1 331.5 441.3 8.5 310.2 435.5 8.1
50.0 391.6 297.1 14.5 387.9 317.7 13.5 383.9 340.0 12.6 379.5 364.0 11.7 374.8 389.5 10.8 366.0 412.1 10.0 353.1 427.2 9.3 340.2 441.9 8.7 313.5 424.6 8.3
52.0 403.4 300.9 14.8 399.6 321.1 13.8 395.4 343.3 12.8 390.8 367.0 11.9 385.9 392.4 11.0 375.7 412.9 10.3 362.4 427.9 9.6 349.2 442.5 8.9 316.5 412.9 8.6
55.0 421.3 306.4 15.2 417.2 326.8 14.2 412.9 348.5 13.2 408.1 372.3 12.3 402.9 397.4 11.4 390.4 414.3 10.6 376.6 429.0 9.9 362.8 443.6 9.3 320.4 394.8 9.1
MODEL: YCIV0397S/P S_IPLV = 13.4 P_IPLV = 15.5
AIR TEMPERATURE ON - CONDENSER (°F)
LCWT 75.0 80.0 85.0 90.0 95.0 100.0 105.0 110.0 115.0
(°F) TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER
40.0 377.3 318.0 13.0 374.2 341.7 12.1 370.7 366.9 11.2 366.9 393.4 10.4 362.9 421.2 9.6 358.2 452.5 8.9 350.0 477.2 8.3 340.3 499.0 7.7 330.6 520.6 7.2
42.0 389.1 320.9 13.3 385.8 344.5 12.4 382.2 369.8 11.5 378.2 396.4 10.6 374.0 424.1 9.9 369.0 455.5 9.1 359.8 479.0 8.5 349.7 501.0 7.9 339.5 522.9 7.4
44.0 401.2 324.1 13.6 397.8 347.7 12.6 394.0 372.7 11.7 389.8 399.4 10.9 385.3 427.3 10.1 380.1 458.7 9.3 369.8 481.0 8.7 359.3 502.9 8.1 348.7 524.9 7.5
45.0 407.4 325.7 13.7 403.8 349.3 12.8 399.9 374.5 11.9 395.7 400.9 11.0 391.0 428.9 10.2 385.4 459.7 9.4 374.9 481.9 8.8 364.2 503.9 8.2 350.8 519.5 7.7
46.0 413.5 327.6 13.9 410.0 350.9 12.9 406.0 376.1 12.0 401.6 402.7 11.1 396.9 430.5 10.3 390.7 460.7 9.5 380.0 482.8 8.9 369.2 504.8 8.3 352.7 513.1 7.8
48.0 426.1 331.2 14.1 422.4 354.4 13.2 418.2 379.4 12.3 413.7 406.0 11.4 408.7 434.0 10.6 401.5 462.6 9.8 390.5 484.6 9.1 379.2 506.8 8.5 356.3 500.1 8.1
50.0 439.0 335.0 14.4 435.1 358.2 13.4 430.8 382.9 12.5 426.0 409.4 11.6 420.9 437.5 10.8 412.6 464.5 10.0 401.1 486.6 9.3 389.5 508.7 8.7 360.0 487.0 8.4
52.0 452.0 339.1 14.7 448.0 362.0 13.7 443.5 386.8 12.8 438.6 413.1 11.9 433.2 441.1 11.0 423.8 466.5 10.2 411.9 488.5 9.5 400.0 510.5 8.9 363.7 474.1 8.7
55.0 471.7 343.8 15.1 467.3 368.2 14.1 462.8 392.7 13.1 457.8 419.1 12.2 452.3 446.8 11.4 441.0 469.8 10.6 428.7 491.5 9.9 416.1 513.5 9.2 368.8 455.8 9.1
