INTRODUCTION TO THE GRAPHICAL USER INTERFACE
1-8 XEROX DOCUPRINT 4850/4890 IPS GUIDE TO CONFIGURING AND MANAGING THE SYSTEM
Exiting a window
You can exit most IPS windows by clicking the left mouse button on
a Quit, Done, or Cancel button. Sometimes an Apply button closes
the window after applying what has been specified or selected.
Pin buttons In addition, on certain windows, there is a small button in the shape
of a push-pin in the upper-left corner on the title bar (illustrated in the
following examples).
•
If the pin is “out:”
Figure 1-8. Window with pin button “out”
— You can exit the window by double-clicking the pin button.
— The window automatically closes after you make a
selection from it.
— To change the pin to the “in” position, single-click the pin
button.
•
If the pin is “in:”
Figure 1-9. Upper-left portion of a window with pin button “in”
— You can exit the window by single-clicking the pin button.
— The window remains open after you make selections from
it.
