FIG. 45 – CONTINUED
3
Remote Modem Current Limit = 100 %
Pulldown Demand Limit = 100 %
Pulldown Demand Time = 0 Min
[Skip the following section if Motor Type is not Mod A
SSS]
Liquid-Cooled Solid State Starter
-------------------------------------------------------------------------
Local Motor Current Limit = 100 %
Remote ISN Current Limit = 100 %
Remote Analog Current Limit = 100 %
Remote Digital Current Limit = 100 %
Remote Modem Current Limit = 100 %
Pulldown Demand Limit = 100 %
Pulldown Demand Time = 0 Min
Scale/Model = 600
V,
281
A
Supply Voltage Range = Disabled
Full Load Amps = 150 A
Current Imbalance Check = Disabled
[Skip the following section if Motor Type is not Mod B
SSS]
Liquid-Cooled Solid State Starter
-------------------------------------------------------------------------
Local Motor Current Limit = 100 %
Remote ISN Current Limit = 100 %
Remote Analog Current Limit = 100 %
Remote Digital Current Limit = 100 %
Remote Modem Current Limit = 100 %
Pulldown Demand Limit = 100 %
Pulldown Demand Time = 0 Min
Starter Model = 33L
Voltage Range = Disabled
Full Load Amps = 215 A
Starting Current = 1460 A
Open SCR = Disabled
[Skip the following section if Motor Type is not VSD]
Variable Speed Drive
-------------------------------------------------------------------------
Local Motor Current Limit = 100 %
Remote ISN Current Limit = 100 %
Remote Analog Current Limit = 100 %
Remote Digital Current Limit = 100 %
Remote Modem Current Limit = 100 %
Pulldown Demand Limit = 100 %
Pulldown Demand Time = 0 Min
Motor HP = 351 HP
Power Line Frequency = 60 Hz
[Skip the following section if Motor Type is not VSD]
Harmonic Filter Data
-------------------------------------------------------------------------
Filter Operation = Enabled
Motor HP = 351 HP
YORK SCHEDULE
CHILLER ID 0
© 1997 - 1999 YORK international corporation
mon 21 jun 1999 1:28:25 pm
schedule =
OFF
Standard Schedule
---------------------------------------------------------------------------
Sun StarT = Off Stop = Off
MOn Start = 06:00 AM Stop = 06:00 PM
Tue Start = 06:00 AM Stop = 06:00 PM
Wed Start = 06:00 AM Stop = 06:00 PM
Th u Start = 06:00 AM Stop = 06:00 PM
Fri Start = 06:00 AM Stop = 06:00 PM
Sat Start = Off Stop = Off
Exception Days
---------------------------------------------------------------------------
15 jul 1999 start =
08:00 am stop = 08:00 pm
16 jul 1999 start =
08:00 am stop = 08:00 pm
17 jul 1999 start =
08:00 am stop = 08:00 pm
18 jul 1999 start =
08:00 am stop = 08:00 pm
FIG. 46 – SAMPLE PRINTOUT
(SCHEDULE
RE
PORT)
