Chapter 3 Wizard Setup
P-2302HWUDL-P1 Series User’s Guide
56
The following table describes the labels in this screen.
3.2.6 WAN IP Address Assignment
This screen appears if you select Use fixed IP address provided by your ISP in the previous
screen. Use this screen to set up your static IP address. The fields depend on the Connection
Type you select in the
ISP Parameters screen.
3.2.6.1 Ethernet
Figure 22 Connection Wizard > IP Address (Ethernet)
Table 13 Connection Wizard > IP Address
LABEL DESCRIPTION
Get automatically
from your ISP
Select this if your ISP did not assign you a static IP address.
Use fixed IP
address provided
by your ISP
Select this if your ISP assigned you a static IP address.
< Back Click this to go to the previous screen.
Next > Click this to go to the next screen.
Exit Click this to close this screen and return to the main screen.
