ZyXEL Communications P-2302HWUDL-P1 Series - Manual (Page 55)

Chapter 3 Wizard Setup
P-2302HWUDL-P1 Series User’s Guide
55
Figure 20 Connection Wizard > ISP Parameters (PPPoE)
The following table describes the labels in this screen.
3.2.5 Your IP Address
Figure 21 Connection Wizard > IP Address
Table 12 Connection Wizard > ISP Parameters (PPPoE)
LABEL DESCRIPTION
Connection Type Select PPP over Ethernet.
Service Name Enter the PPP service name provided by your ISP. If your ISP did not provide a
service name, leave this field blank.
User Name Enter the user name provided by your ISP.
Password Enter the password provided by your ISP.
< Back Click this to go to the previous screen.
Next > Click this to go to the next screen.
Exit Click this to close this screen and return to the main screen.
