ZyXEL NWA570N User’s Guide
95
C
H A P T E R
9
Product Specifications and Wall-
Mounting Instructions
The following tables summarize the NWA570N’s hardware and firmware features.
Hardware Specifications
Table 29 Hardware Specifications
Dimensions 190 mm (Wide) × 128 mm (Deep) × 33 mm (High)
Weight 203 g
Ethernet Port Four auto-negotiating, auto MDI/MDI-X 10/100 Mbps RJ-45 Ethernet ports
Cabling Type 4 x LAN UTP Category 5 or better
RESET button The reset button is built into the rear panel. Use this button to restart the
device or restore the factory default password.
WPS button The WPS (WI-Fi Protected Setup) button is built into the rear panel. Use
this button to set up a WPS connection with another WPS enabled device.
Antenna 3 external detachable 2 dBi dipole antenna with R-SMA connectors
LEDs Status LEDs:
•
Power
• Ethernet
• WLAN
• WPS
Power Requirements 12 V DC: 1 A Max
Operation Environment Temperature: 0º C ~ 50º C
Humidity: 20% ~ 95% RH
Storage Environment Temperature: -20º ~ 70º C
Humidity: 20% ~ 95% RH
Distance between the
centers of the holes on
the device’s back.
74 mm
