Chapter 4 Status Screen
ZyXEL NWA570N User’s Guide
49
4.2.2 Association List
Click Status and then the View Association List button to display the Association List
screen. When the device is not in wireless client mode, this screen displays which wireless
stations are currently associated to the device in the Association List screen.
Figure 24 Status: View Association List
The following table describes the labels in this screen.
When the device is in wireless client mode, this screen displays details of the access point to
which the ZyXEL Device is associated.
Broadcast
Packets
This row displays the numbers of broadcast packets received and transmitted by
the wireless adapter.
Multicast
Packets
This row displays the numbers of multicast packets received and transmitted by
the wireless adapter.
Total Packets This row displays the numbers of all types of packets received and transmitted by
the wireless adapter.
Total Bytes This row displays the numbers of bytes received and transmitted by the wireless
adapter.
System Up Time This is the total time the device has been on.
Poll Interval(s) Enter the time interval for refreshing statistics.
Set Interval Click this button to apply the new poll interval you entered above.
Stop Click this button to stop refreshing statistics.
Table 6 Status: View Statistics
LABEL DESCRIPTION
Table 7 Status: View Association List
LABEL DESCRIPTION
# This is the index number of an associated wireless station.
MAC Address This field displays the MAC address of an associated wireless station.
IP Address This field displays the IP address of an associated wireless station.
Signal Strength This field displays the signal strength of each associated wireless station.
Status This field displays Associated for associated wireless stations.
Rescan Click Rescan to check for associated wireless stations.
