Chapter 1 Introducing the ZyXEL Device
ZyXEL NWA570N User’s Guide
25
Figure 3 Wireless Client Application
1.2.4 Bridge / Repeater
The ZyXEL Device can act as a wireless network bridge and establish wireless links with
other APs. The ZyXEL Devices in the following example are using bridge mode with a star
configuration. A, B, C and D are connected to independent wired networks and have bridge
connections at the same time (B, C and D can communicate with A).
