Chapter 4 Status Screen
ZyXEL NWA570N User’s Guide
47
4.1.3 Navigation Panel
After you enter the password, use the links on the navigation panel to go to the various
screens.
The following table describes the sub-menus.
Firmware
Version
This is the firmware version and the date the firmware was created.
IP Settings
IP Address This is the Ethernet port IP address.
Subnet Mask This is the Ethernet port subnet mask.
Gateway IP
Address
This is the IP address of a gateway. Leave this field as 0.0.0.0 if you do not know
it.
Wireless Settings
SSID This is the descriptive name used to identify the device in a wireless network.
Channel This field displays the radio channel the device is currently using.
Encryption
Method
This field shows the type of data encryption that is enabled on the wireless
network:
WEP (WEP or 802.1x)
TKIP (WPA or WPA-PSK)
AES (WPA2 or WPA2-PSK)
TKIP + AES (WPA & WPA2 or WPA-PSK & WPA2-PSK)
or
Disable (no security)
MAC Filter This field shows whether MAC filter is enabled or not. With MAC filtering, you can
allow or deny access to the device based on the MAC addresses of the wireless
stations.
View Statistics Click View Statistics to see performance statistics such as number of packets
sent and number of packets received.
View Association
List
Click View Association List to show the wireless stations that are currently
associated to the device.
Table 4 Status
LABEL DESCRIPTION
Table 5 Screens Summary
LINK TAB FUNCTION
Status This screen shows the ZyXEL Device’s general device, system and
interface status information. Use this screen to access the wizard, and
summary statistics tables.
System Use this screen to configure the device name and IP address assignment
settings.
Wireless Wireless
Settings
Use this screen to configure the wireless LAN.
Security Use this screen to configure the wireless LAN’s security settings.
MAC Filter Use the MAC filter screen to configure the ZyXEL Device to block or allow
only certain devices to associate with the ZyXEL Device.
WPS settings This shows the status of Wi-Fi Protected Setup (WPS) on your device.
