TABLE 55: ELECTRICAL DATA 30 TON WITH ELECTRIC HEAT AND POWER EXHAUST R22
V OLTAGE
E LECTRIC H EAT
C OMPRESSORS
( EACH )
OD F AN M OTORS
( EACH )
S UPPLY B LOWER P WR E XH M OTOR
MCA 1
(A MPS )
M AX
F USE
2 /
B REAKER
3
S IZE
O PTION KW S TAGES Q TY . RLA LRA MCC Q TY FLA HP FLA HP FLA
208-3-60
E4 40 1 3 37.2 239 58.0 3 5.8
10 30.8
7.5 24.2 189 225
10 30.8 196 225
15 46.2 214 250
15 46.2
7.5 24.2 207 250
10 30.8 214 250
15 46.2 229 250
20 59.4
7.5 24.2 224 250
10 30.8 230 250
15 46.2 246 300
25 74.8
7.5 24.2 243 300
10 30.8 249 300
15 46.2 265 300
E8 80 2 3 37.2 239 58.0 3 5.8
10 30.8
7.5 24.2 229 250
10 30.8 236 250
15 46.2 255 300
15 46.2
7.5 24.2 249 250
10 30.8 255 300
15 46.2 271 300
20 59.4
7.5 24.2 265 300
10 30.8 272 300
15 46.2 287 300
25 74.8
7.5 24.2 284 350
10 30.8 291 350
15 46.2 306 350
230-3-60
E4 40 1 3 37.2 239 58.0 3 5.8
10 28.0
7.5 22.0 184 200
10 28.0 190 225
15 42.0 205 225
15 42.0
7.5 22.0 199 225
10 28.0 205 225
15 42.0 219 250
20 54.0
7.5 22.0 214 250
10 28.0 220 250
15 42.0 234 250
25 68.0
7.5 22.0 232 250
10 28.0 238 300
15 42.0 252 300
E8 80 2 3 37.2 239 58.0 3 5.8
10 28.0
7.5 22.0 249 250
10 28.0 255 300
15 42.0 273 300
15 42.0
7.5 22.0 267 300
10 28.0 273 300
15 42.0 287 300
20 54.0
7.5 22.0 282 300
10 28.0 288 300
15 42.0 302 350
25 68.0
7.5 22.0 299 350
10 28.0 305 350
15 42.0 319 350
