TABLE 42: COMPONENT STATIC RESISTANCE
1, 2
COMPONENT COIL
LOSSES
CFM
6,000 8,000 10,000 12,000 14,000 16,000 18,000
S TD . 25 T ON , D RY -0.06 -0.08 -0.10 -0.13 - - -
S TD . 25 T ON , W ET Baseline Baseline Baseline Baseline Baseline Baseline Baseline
S TD . 30 T ON , D RY -0.045 -0.075 -0.112 -0.157 -0.207 -0.264 -0.326
S TD . 30 T ON , W ET Baseline Baseline Baseline Baseline Baseline Baseline Baseline
H I C AP 30 T ON , D RY -0.019 -0.035 -0.052 -0.073 -0.098 -0.124 -0.155
H I C AP 30 T ON , W ET 0.042 0.069 0.103 0.142 0.186 0.236 0.290
S TD . 40 T ON , D RY -0.030 -0.051 -0.076 -0.106 -0.140 -0.177 -0.219
S TD . 40 T ON , W ET Baseline Baseline Baseline Baseline Baseline Baseline Baseline
H I C AP 40 T ON , D RY -0.020 -0.033 -0.050 -0.069 -0.092 -0.116 -0.144
H I C AP 40 T ON , W ET 0.023 0.038 0.057 0.079 0.105 0.133 0.164
F ILTER L OSSES
2” TA OR HI E FF . Baseline Baseline Baseline Baseline Baseline Baseline Baseline
R IGID 6”, 65% 0.048 0.080 0.119 0.165 0.217 0.274 0.338
R IGID 6”, 95% 0.189 0.308 0.448 0.609 0.790 0.988 1.205
IGV L OSSES
25 & 30 T ON 0.048 0.085 0.132 0.190 0.259 0.338 0.428
40 T ON 0.027 0.049 0.076 0.110 0.149 0.195 0.246
G AS H EAT
267 MBH H EAT 0.106 0.141 0.177 0.212 0.247 0.283 0.318
533 MBH H EAT 0.212 0.283 0.353 0.424 0.495 0.566 0.636
800 MBH H EAT 0.318 0.423 0.531 0.636 0.741 0.849 0.954
E LECTRIC H EAT 0.050 0.100 0.150 0.310 0.430 0.530 0.680
E CONOMIZER 0.063 0.104 0.153 0.210 0.276 0.349 0.429
P OWER E XHAUST 0.046 0.081 0.127 0.182 0.248 0.324 0.410
1. Baseline losses based on system/cabinet effects, wet standard coil and 2” throwaway filters at 70°F, 0 feet elevation with standard air.
2. See Tables 10, 12, 15, 18, 21 and 23 for hot water and steam water coil static resistance.
