246653-YTG-E-0108
Johnson Controls Unitary Products 55
4. Shaded RPMs require Class II blower.
A IRFLOW (CFM)
A VAILABLE E XTERNAL S TATIC P RESSURE (IWG)
3.2 3.4 3.6 3.8 4.0
RPM BHP
3 RPM BHP
3 RPM BHP
3 RPM BHP
3 RPM BHP
3
8000 1315 6.0 1345 6.4 1375 6.7 1405 7.1 1433 7.4
9000 1360 6.9 1389 7.3 1417 7.6 1445 8.0 1472 8.4
10000 1411 7.9 1438 8.3 1464 8.7 1491 9.1 1517 9.5
11000 1466 9.0 1492 9.5 1517 9.9 1542 10.3 1567 10.8
12000 1526 10.3 1550 10.8 1575 11.2 1599 11.7 1622 12.2
13000 1590 11.8 1613 12.3 1635 12.7 1658 13.2 1681 13.7
14000 1656 13.4 1678 13.9 1700 14.4 1721 14.9 1743 15.5
15000 1725 15.2 1745 15.8 1766 16.3 1787 16.9 1808 17.4
16000 1796 17.3 1816 17.8 1835 18.4 1855 19.0 1875 19.5
17000 1868 19.5 1888 20.1 1907 20.6 1926 21.2 1944 21.8
18000 1943 21.9 1961 22.5 1980 23.2 1998 23.8 2016 24.4
19000 2019 24.6
20000
A IRFLOW (CFM)
A VAILABLE E XTERNAL S TATIC P RESSURE (IWG)
4.2 4.4 4.6 4.8 5.0
RPM BHP
3 RPM BHP
3 RPM BHP
3 RPM BHP
3 RPM BHP
3
8000 1462 7.8 1490 8.2 1518 8.6 1545 9.0 1572 9.4
9000 1500 8.8 1526 9.2 1553 9.6 1579 10.0 1605 10.4
10000 1543 9.9 1569 10.4 1594 10.8 1619 11.2 1644 11.7
11000 1592 11.2 1617 11.7 1640 12.1 1664 12.6 1688 13.0
12000 1645 12.6 1669 13.1 1692 13.6 1715 14.1 1737 14.6
13000 1703 14.2 1725 14.7 1747 15.2 1769 15.7 1791 16.2
14000 1764 16.0 1785 16.5 1806 17.1 1827 17.6 1847 18.1
15000 1828 18.0 1848 18.5 1868 19.1 1888 19.6 1908 20.2
16000 1895 20.1 1914 20.7 1933 21.2 1952 21.8 1971 22.4
17000 1963 22.5 1981 23.1 2000 23.7 2018 24.3 2036 24.9
18000 2033 25.0
A IRFLOW (CFM)
A VAILABLE E XTERNAL S TATIC P RESSURE (IWG)
5.2 5.4 5.6 5.8 6.0
RPM BHP
3 RPM BHP
3 RPM BHP
3 RPM BHP
3 RPM BHP
3
8000 1599 9.8 1624 10.2 1650 10.6 1675 11.0 1701 11.4
9000 1630 10.9 1655 11.3 1680 11.7 1705 12.2 1729 12.6
10000 1668 12.1 1692 12.6 1716 13.0 1740 13.5 1763 13.9
11000 1712 13.5 1734 14.0 1757 14.5 1780 14.9 1803 15.4
12000 1759 15.0 1782 15.5 1804 16.0 1825 16.6 1847 17.1
13000 1812 16.8 1833 17.3 1854 17.8 1875 18.4 1896 18.9
14000 1868 18.7 1888 19.2 1908 19.8 1928 20.3 1948 20.8
15000 1927 20.7 1947 21.3 1966 21.9 1985 22.5 2004 23.0
16000 1990 23.0 2008 23.6 2027 24.2 2045 24.8
17000
18000
1. Fan performance is based on wet evaporator coils, clean 2” throwaway filters and system/cabinet effects at standard air density and 0 feet elevation.
2. Refer to Tables 10, 12, 15, 18, 21, 23 and 42 for component additions and deductions to fan performance tables.
3. BHP includes drive losses.
TABLE 41: FAN PERFORMANCE - 40 TON AIRFOIL
1,2
(CONTINUED)
