246653-YTG-E-0108
64 Johnson Controls Unitary Products
TABLE 49: ELECTRICAL DATA 30 TON WITH ELECTRIC HEAT R22
V OLTAGE
C OMPRESSORS
( EACH )
OD F AN M OTORS
( EACH )
S UPPLY B LOWER E LECTRIC H EAT
MCA 1
(A MPS )
M AX
F USE
2 /
B REAKER
3
S IZE
Q TY . RLA LRA MCC QTY FLA HP FLA O PTION KW
A PPLIED
KW
S TAGES
208-3-60 3 37.2 239 58.0 3 4.5
10 30.8 E4 40 30 1 165 200
15 46.2 E4 40 30 1 183 225
20 59.4 E4 40 30 1 199 250
25 74.8 E4 40 30 1 219 250
10 30.8 E8 80 60 2 205 225
15 46.2 E8 80 60 2 225 250
20 59.4 E8 80 60 2 241 300
25 74.8 E8 80 60 2 260 300
230-3-60 3 37.2 239 58.0 3 4.5
10 28.0 E4 40 36.8 1 162 175
15 42.0 E4 40 36.8 1 177 200
20 54.0 E4 40 36.8 1 192 225
25 68.0 E4 40 36.8 1 210 250
10 28.0 E8 80 73.6 2 227 250
15 42.0 E8 80 73.6 2 245 250
20 54.0 E8 80 73.6 2 260 300
25 68.0 E8 80 73.6 2 277 300
460-3-60 3 17.2 125 27.0 3 2.2
10 14.0 E4 40 36.8 1 78 90
15 21.0 E4 40 36.8 1 86 100
20 27.0 E4 40 36.8 1 94 110
25 34.0 E4 40 36.8 1 103 125
10 14.0 E8 80 73.6 2 114 125
15 21.0 E8 80 73.6 2 122 125
20 27.0 E8 80 73.6 2 130 150
25 34.0 E8 80 73.6 2 139 150
10 14.0 E1 108 99.4 2 147 175
15 21.0 E1 108 99.4 2 156 175
20 27.0 E1 108 99.4 2 164 175
25 34.0 E1 108 99.4 2 172 200
575-3-60 3 12.4 80 19.3 3 1.7
10 11.0 E4 40 36.8 1 62 70
15 17.0 E4 40 36.8 1 69 80
20 22.0 E4 40 36.8 1 76 90
25 27.0 E4 40 36.8 1 82 100
10 11.0 E8 80 73.6 2 91 100
15 17.0 E8 80 73.6 2 98 110
20 22.0 E8 80 73.6 2 104 125
25 27.0 E8 80 73.6 2 111 125
10 11.0 E1 108 99.4 2 118 150
15 17.0 E1 108 99.4 2 125 150
20 22.0 E1 108 99.4 2 131 150
25 27.0 E1 108 99.4 2 138 150
1. Minimum Circuit Ampacity.
2. Dual Element, Time Delay Type.
3. HACR type per NEC
