P-2602R/RL-DxA Series User’s Guide
70 Chapter 5 Bandwidth Management Wizard
The following fields describe the label in this screen.
4 If you select Service Setup, use the second wizard screen to select the services that you
want to apply bandwidth management and select the priorities that you want to apply to
the services listed.
Figure 31 Bandwidth Management Wizard: Service Configuration
The following table describes the labels in this screen.
Table 14 Bandwidth Management Wizard: General Information
LABEL DESCRIPTION
Active Select the Active check box to have the ZyXEL Device apply bandwidth
management to traffic going out through the ZyXEL Device’s WAN or LAN port.
Select Auto Classifier to automatically allocate bandwidth to packets based on the
packet size or Services Setup to allocate bandwidth based on the service
requirements.
Back Click Back to display the previous screen.
Next Click Next to proceed to the next screen.
Exit Click Exit to close the wizard screen without saving.
Table 15 Bandwidth Management Wizard: Service Configuration
LABEL DESCRIPTION
Active Select Active to enable bandwidth management for service specified traffic.
Select an entry’s Active check box to turn on bandwidth management for the service/
application.
Service These fields display the services names.
