2 web configurator main screen, 1 title bar, Figure 9 main screen – ZyXEL Communications P-2602R-DxA Series User Manual
Page 48: Ac d b
P-2602R/RL-DxA Series User’s Guide
48
Chapter 2 Introducing the Web Configurator
2.2 Web Configurator Main Screen
Figure 9 Main Screen
As illustrated above, the main screen is divided into these parts:
• A - title bar
• B - navigation panel
• C - main window
• D - status bar
2.2.1 Title Bar
The title bar allows you to change the language and provides some icons in the upper right
corner.
A
C
D
B
