P-2602R/RL-DxA Series User’s Guide

Chapter 23 Diagnostic

249

C

H A P T E R

23

Diagnostic

These read-only screens display information to help you identify problems with the ZyXEL
Device.

23.1 General Diagnostic

Click Maintenance > Diagnostic to open the screen shown next.

Figure 141 Diagnostic: General

The following table describes the fields in this screen.

23.2 DSL Line Diagnostic

Click Maintenance > Diagnostic > DSL Line to open the screen shown next.

Table 92 Diagnostic: General

LABEL

DESCRIPTION

TCP/IP

Address

Type the IP address of a computer that you want to ping in order to test a connection.

Ping

Click this button to ping the IP address that you entered.
