Prestige 642R Series ADSL Router

2-4

Hardware Installation & Setup

Step 2. Connect a cable from the double jack end of the Y-Connector to the “wall side” of the

microfilter.

Step 3. Connect another cable from the double jack end of the Y-Connector to the Prestige.
Step 4. Connect the “phone side” of the microfilter to your telephone as shown in the following figure.

Figure 2-4

Connecting a Microfilter

2.6 Special Note for P642 ISDN Users

Please note that section 2.4 “Connecting a POTS Splitter” and sections 2.5 “Telephone Microfilters” of
the P642 User’s Guide do not apply for P642 ISDN users.

Wall
Jack

Prestige

Y -CONNECTOR

Wall
Side

Phone
Side

Microfilter
