P-660R/H-D Series User’s Guide
Chapter 4 Wizard Setup for Media Bandwidth Management 60
The following table describes the labels in this screen.
2 The Prestige automatically creates the bandwidth class for each service you select. You
may set the priority for each bandwidth class in the second wizard screen.
Figure 17 Media Bandwidth Mgnt. Wizard Setup: Second Screen
The following table describes the fields in this screen.
Table 13 Media Bandwidth Mgnt. Wizard Setup: First Screen
LABEL DESCRIPTION
Active Select the Active check box to have the Prestige apply bandwidth management
to traffic going out through the Prestige’s WAN or LAN port.
Select the service to
apply bandwidth
management.
These checkboxes are applicable when you select the Active check box above.
Create bandwidth management classes by selecting services from the list
provided.
•
XBox Live
• VoIP (SIP)
• FTP
• E-Mail
• eMule
• WWW
Refer to Table 14 on page 60 for more information.
Next Click Next to continue.
Table 14 Media Bandwidth Mgnt. Wizard Setup: Second Screen
LABEL DESCRIPTION
Service These fields display the service(s) selected in the previous screen.
Priority Select High, Mid or Low priority for each service to have your Prestige use a priority
for traffic that matches that service.
Select Others if you want to specify the service priority level in the Advanced Setup
- Media Bandwidth Mgnt. screen.
If the rules set up in this wizard are changed in Advanced Setup - Media Bandwidth
Mgnt. - Class Configuration, then the service priority radio button will be set to
Others.
The Class Configuration screen allow you to edit these rule configurations.
