P-660R/H-D Series User’s Guide
375
Appendix L Internal SPTGEN
This section covers Prestige Internal SPTGEN screens.
The following are Internal SPTGEN screens associated with the SMT screens of your Prestige.
Table 131 Abbreviations Used in the Example Internal SPTGEN Screens Table
ABBREVIATION
MEANING
FIN
Field Identification Number (not seen in SMT screens)
FN
Field Name
PVA
Parameter Values Allowed
INPUT
An example of what you may enter
*
Applies to the Prestige.
Table 132 Menu 1 General Setup (SMT Menu 1)
/ Menu 1 General Setup (SMT Menu 1)
FIN
FN
PVA
INPUT
10000000 =
Configured
<0(No) | 1(Yes)>
= 0
10000001 =
System Name
= Prestige
10000002 =
Location
=
10000003 =
Contact Person's Name
=
10000004 =
Route IP
<0(No) | 1(Yes)>
= 1
10000006 =
Bridge
<0(No) | 1(Yes)>
= 0
Table 133 Menu 3 (SMT Menu 3 )
/ Menu 3.1 General Ethernet Setup (SMT menu 3.1)
FIN
FN
PVA
INPUT
30100001 =
Input Protocol filters Set 1
= 2
30100002 =
Input Protocol filters Set 2
= 256
30100003 =
Input Protocol filters Set 3
= 256
30100004 =
Input Protocol filters Set 4
= 256
30100005 =
Input device filters Set 1
= 256
30100006 =
Input device filters Set 2
= 256
30100007 =
Input device filters Set 3
= 256
30100008 =
Input device filters Set 4
= 256
30100009 =
Output protocol filters Set 1
= 256
30100010 =
Output protocol filters Set 2
= 256
30100011 =
Output protocol filters Set 3
= 256
30100012 =
Output protocol filters Set 4
= 256
30100013 =
Output device filters Set 1
= 256
