P-660R/H-D Series User’s Guide
305 Chapter 34 IP Policy Routing
1 Check Menu 25.1 — IP Routing Policy Setup to see if the rule is added correctly.
2 Create another policy set in menu 25.
3 Create a rule in menu 25.1 for this set to route packets from any host ( IP=0.0.0.0
means any host) with protocol TCP and port FTP access through another gateway
(192.168.1.100).
Figure 202 IP Routing Policy Example
4 Check Menu 25.1 - IP Routing Policy Setup to see if the rule is added correctly.
5 Apply both policy sets in menu 3.2 as shown next.
Menu 25.1.1 - IP Routing Policy
Policy Set Name= set2
Active= Yes
Criteria:
IP Protocol = 6
Type of Service= Don't Care Packet length= 10
Precedence = Don't Care Len Comp= Equal
Source:
addr start= 0.0.0.0 end= N/A
port start= 0 end= N/A
Destination:
addr start= 0.0.0.0 end= N/A
port start= 20 end= 21
Action= Matched
Gateway type = Gateway addr Gateway addr = 192.168.1.100
Type of Service= No Change Gateway node = 0
Precedence = No Change Log= No
Press ENTER to Confirm or ESC to Cancel:
