P-660R/H-D Series User’s Guide
233 Chapter 26 Network Address Translation (NAT)
Figure 134 Menu 15.1 Address Mapping Sets
26.3.1.1 SUA Address Mapping Set
Enter 255 to display the next screen (see also Section 26.1.1 on page 230 ). The fields in this
menu cannot be changed.
Figure 135 Menu 15.1.255 SUA Address Mapping Rules
The following table explains the fields in this menu.
Menu 15.1.255 is read-only.
Menu 15.1 - Address Mapping Sets
1.ACL Default Set
2.
3.
4.
5.
6.
7.
8.
255. SUA (read only)
Enter Menu Selection Number:
Menu 15.1.255 - Address Mapping Rules
Set Name=
Idx Local Start IP Local End IP Global Start IP Global End IP Type
--- --------------- --------------- --------------- ------------- ----
1. 0.0.0.0 255.255.255.255 0.0.0.0 M-1
2. 0.0.0.0 Server+
3.
4.
5.
6.
7.
8.
9.
10.
Press ENTER to Confirm or ESC to Cancel:
Table 86 SUA Address Mapping Rules
FIELD DESCRIPTION
Set Name This is the name of the set you selected in menu 15.1 or enter the name of a new set
you want to create.
Idx This is the index or rule number.
Local Start IP Local Start IP is the starting local IP address (ILA).
