P-660R/H-D Series User’s Guide
251 Chapter 28 Filter Configuration
Figure 158 NetBIOS_LAN Filter Rules Summary
Figure 159 IGMP Filter Rules Summary
28.3 Filter Rules Summary Menus
The following tables briefly describe the abbreviations used in menus 21.1.1 and 21.1.2.
Menu 21.1.3 - Filter Rules Summary
# A Type Filter Rules M m n
- - ---- ------------------------------------------------------------ - - -
1 Y IP Pr=17, SA=0.0.0.0, SP=137, DA=0.0.0.0, DP=53 N D F
2 N
3 N
4 N
5 N
6 N
Enter Filter Rule Number (1-6) to Configure:
Menu 21.1.4 - Filter Rules Summary
# A Type Filter Rules M m n
- - ---- ------------------------------------------------------------ - - -
1 Y Gen Off=0, Len=3, Mask=ffffff, Value=01005e N D F
2 N
3 N
4 N
5 N
6 N
Enter Filter Rule Number (1-6) to Configure:
Table 89 Abbreviations Used in the Filter Rules Summary Menu
FIELD DESCRIPTION
# The filter rule number: 1 to 6.
A Active: “Y” means the rule is active. “N” means the rule is inactive.
Type The type of filter rule: “GEN” for Generic, “IP” for TCP/IP.
Filter Rules These parameters are displayed here.
M More.
“Y” means there are more rules to check which form a rule chain with the present rule.
An action cannot be taken until the rule chain is complete.
“N” means there are no more rules to check. You can specify an action to be taken for
instance, forward the packet, drop the packet or check the next rule. For the latter, the
next rule is independent of the rule just checked.
