P-660R/H-D Series User’s Guide
Chapter 23 Remote Node Configuration
214
1 In menu 11.1, make sure IP is among the protocols in the Route field.
2 Move the cursor to the Edit IP/Bridge field, press [SPACE BAR] to select Yes, then
press [ENTER] to display Menu 11.3 – Remote Node Network Layer Options.
Figure 112 Menu 11.3 Remote Node Network Layer Options
The next table explains fields in Menu 11.3 – Remote Node Network Layer Options.
Menu 11.3 - Remote Node Network Layer Options
IP Options: Bridge Options:
IP Address Assignment = Static Ethernet Addr Timeout(min)= N/A
Rem IP Addr = 0.0.0.0
Rem Subnet Mask= 0.0.0.0
My WAN Addr= 0.0.0.0
NAT= SUA Only
Address Mapping Set= N/A
Metric= 2
Private= No
RIP Direction= None
Version= RIP-1
Multicast= None
IP Policies=
Enter here to CONFIRM or ESC to CANCEL:
Table 80 Menu 11.3 Remote Node Network Layer Options
FIELD
DESCRIPTION
IP Address
Assignment
Press [SPACE BAR] and then [ENTER] to select Dynamic if the remote node is using
a dynamically assigned IP address or Static if it is using a static (fixed) IP address.
You will only be able to configure this in the ISP node (also the one you configure in
menu 4), all other nodes are set to Static.
Rem IP Addr
This is the IP address you entered in the previous menu.
Rem Subnet
Mask
Type the subnet mask assigned to the remote node.
My WAN Addr
Some implementations, especially UNIX derivatives, require separate IP network
numbers for the WAN and LAN links and each end to have a unique address within
the WAN network number. In that case, type the IP address assigned to the WAN port
of your Prestige.
NOTE: Refers to local Prestige address, not the remote router address.
NAT
Press [SPACE BAR] and then [ENTER] to select Full Feature if you have multiple
public WAN IP addresses for your Prestige.
Select SUA Only if you have just one public WAN IP address for your Prestige. The
SMT uses Address Mapping Set 255 (see
).
Select None to disable NAT.
Address
Mapping Set
When Full Feature is selected in the NAT field, configure address mapping sets in
menu 15.1. Select one of the NAT server sets (2-10) in menu 15.2 (see
for details) and type that number here.
When SUA Only is selected in the NAT field, the SMT uses NAT server set 1 in menu
for details).
