P-660R/H-D Series User’s Guide
217 Chapter 23 Remote Node Configuration
Figure 115 Menu 11.5 Remote Node Filter (PPPoA or PPPoE Encapsulation)
23.4.1 Web Configurator Internet Security Filter Rules
In the web configurator, open the Security screen as shown next. Select the predefined filter
rules and click Apply. This section applies to the P-660R-D.
Figure 116 Internet Security
Once you apply the filter rules in the web configurator, filter sets 11 and 12 are automatically
applied in the protocol filters field under Input Filter Sets in SMT menu 11.5.
Note: SMT input protocol filter set numbers that were previously applied are erased
after you apply the Internet Security filter rules in the web configurator. To
reapply them or apply new filter sets, you need to enter the filter set numbers
again along with filter sets 11 and 12. For example, to apply filter sets 1 and 2,
you enter "1, 2, 11, 12".
23.4.2 Web Configurator Filter Sets
When you apply filter rules using the web configurator, filter sets 11 and 12 are automatically
generated in SMT menu 21. This feature is not available on all models.
Menu 11.5 - Remote Node Filter
Input Filter Sets:
protocol filters= 1, 5, 9, 12
device filters=
Output Filter Sets:
protocol filters=
device filters=
Call Filter Sets:
protocol filters=
device filters=
Enter here to CONFIRM or ESC to CANCEL:
