P-660R/H-D Series User’s Guide
167 Chapter 16 Media Bandwidth Management Advanced Setup
Figure 79 Media Bandwidth Mgnt.
The following table describes the links in this screen.
16.11 Configuring Summary
Click Media Bandwidth Management, Summary to open the screen as shown next.
Enable bandwidth management on an interface and set the maximum allowed bandwidth for
that interface.
Refer to Section 16.1 on page 160 for more information.
Figure 80 Media Bandwidth Management: Summary
Table 54 Media Bandwidth Mgnt.
LINK DESCRIPTION
Summary Click this link to display a screen where you can enable bandwidth management
on an interface and set the maximum allowed bandwidth for that interface.
Class Setup Click this link to display a screen thwere you can configure bandwidth classes.
Monitor Click this link to display a screen wehre you can view bandwidth usage.
