PES-1014 User’s Guide
D System Parameters
CATEGORY DEFAULT
VALUE
OPTIONS NOTE
Spanning Tree
Protocol(STP)
Spanning Tree
Configuration
Spanning Tree
Protocol State disable enable/disable Make the STP active or inactive in the switch
Bridge Priority 32768 1-65535 The lower the figure, the higher the chance that the
switch will be a root bridge
Bridge Hello Time 2 sec. 1-10 sec. The time interval for the sending of BPDU packets
between bridges
Bridge Max Age 20 sec. 6-40 sec. Time period a switch waits before sending BPDU
packets if no BPDU packet are received from the root
bridge
Forward Delay 15 sec. 4-30 sec. Time that the switch waits before changing its STP
status from listening/ learning to learning/forwarding
Port Parameters
Port ID N/A 1-24 Select a port for configuring STP parameters
Priority 128 0-255 The higher the value is the easier for a port to be
disabled when a loop occurrs
Path cost 19 1-65535 Spanning Tree Protocol path cost of the port
Port State disable enable/disable If "disable" is displayed, means STP is disabled
