PES-1014 User’s Guide
9-6 Statistics
9.6 Packet Attribute
Move the cursor over the Statistics link and click Packet Attributes to display the Packet Attribute screen shown
next.
Figure 9-6 Packet Attribute
Table 9-5 Packet Attribute Description
FIELD DESCRIPTION
Port ID This is the label of a port.
Unicast TX The total number of good packets addressed to a unicast address that the port transmitted.
Unicast RX The total number of good packets addressed to a unicast address that the port received.
Multicast TX The total number of good packets addressed to a multicast address that the port
transmitted.
Multicast RX The total number of good packets addressed to a multicast address that the port received.
Broadcast TX The total number of good packets addressed to a broadcast address that the port
transmitted.
Broadcast RX The number of good broadcast packets received.
